Pentax DV Series - Submersible Vortex Pumps
Pentax DV Series - Submersible Vortex Pumps
DV210, DVT310
The Pentax DV Series submersible pumps are a “set-back” style vortex impeller pump ideal for heavy duty civil and industrial applications. They are designed for heavy duty use, either mobile or permanent installations. The DV Series can reach flow rates up to 1500 litres per minute.
Specifications:
| Model | HP | kW | Flow Rate | Phase | Volts | Max Head | Outlet |
| DV 210 | 2 | 1.5 | 850LPM | Single | 230 | 13m | 65mm |
| DVT 310 | 3 | 2.2 | 900LPM | Three | 230/400 | 15m | 65mm |
* Can take up to 40-50mm Solids
* Maximum Immersion Depth: 20 meters
* Liquid Temperature: 0-40 degrees
* Cable Length: H07 RNF 10 meters
Features:
* Stainless Steel Shaft
* Thermal Overload Protection
* Double Mechanical Seal With Oil Bath
Applications:
* Heavy Civil & Industrial Applications
* Heavy Duty use, either mobile or Permanent
2 Year Warranty
Original: $1,297.48
-65%$1,297.48
$454.12
Description
Pentax DV Series - Submersible Vortex Pumps
DV210, DVT310
The Pentax DV Series submersible pumps are a “set-back” style vortex impeller pump ideal for heavy duty civil and industrial applications. They are designed for heavy duty use, either mobile or permanent installations. The DV Series can reach flow rates up to 1500 litres per minute.
Specifications:
| Model | HP | kW | Flow Rate | Phase | Volts | Max Head | Outlet |
| DV 210 | 2 | 1.5 | 850LPM | Single | 230 | 13m | 65mm |
| DVT 310 | 3 | 2.2 | 900LPM | Three | 230/400 | 15m | 65mm |
* Can take up to 40-50mm Solids
* Maximum Immersion Depth: 20 meters
* Liquid Temperature: 0-40 degrees
* Cable Length: H07 RNF 10 meters
Features:
* Stainless Steel Shaft
* Thermal Overload Protection
* Double Mechanical Seal With Oil Bath
Applications:
* Heavy Civil & Industrial Applications
* Heavy Duty use, either mobile or Permanent
2 Year Warranty
