Pentax CAMT300 Series - Cast Iron Jet Pump

CAMT300/01

The Pentax CAMT300/01 is self-priming centrifugal jet pump, ideal for house or farm water supply and transfer. The Jet/Venturi design provides the pump with the ability to lift water 8 meters below from the water source. Other applications include drawing water from rivers, ponds, wells, bores and underground tanks. The Cam series are a heavy duty and robust pump.

Explanation of Controller Options

Explanation of Controller Options variable speed

Specifications:

* Power: 2.3kW/3.0 HP
* Head Height: 65m
* Flow Rate: 120 LPM
* Amps: 4.8
* Inlet 40mm/Outlet 32mm
* Three phase voltage range: 220-240v Delta/380-415v star
* Insulation: Class F
* Protection: IP44
* Rating: Continuous

Features:

* Suction Lift - 8 Metres
* Heavy Duty Build
* Cast Iron Body & Motor Bracket
* Ceramic Mechanical Seal
* Stainless Steel Shaft
* Built in thermal overload protection

Operation limitations:

* Liquid temperature range: 0ºc to +50ºc
* Maximum operating pressure: 8bar/116PSI

Applications:

* Suitable for Large Household
* Farm supply
* Water transfer
* Drawing water from rivers, ponds, wells, bores and underground tanks

2 Year Warranty
