Pentax CM Series - Irrigation and Washdown Pumps
Pentax CM Series - Irrigation and Washdown Pumps
The Pentax CM32 Monobloc horizontal centrifugal pumps, constructed to EN 733 standards; widely used in water supplies, pressurization and fire-fighting systems, cooling, heating, irrigation, industrial and agricultural applications; standard supply with counter-flange.
Specifications:
| Model | HP | kW | Flow Rate | Phase | Volts | Max Head | Inlet | Outlet |
| CM32-200C | 5.5 | 4.0 | 450LPM | Three | 400 | 40m | 50mm | 32mm |
| CM32-200A | 10 | 7.5 | 550LPM | Three | 400 | 58m | 50mm | 32mm |
* Inlet/Outlet Size: 50/32mm
* Liquid Temperature: -10 - +90 degrees
* Maximum Operating Pressure: 10Bar
* Enclosure Class: IP55
* Insulation Class: F
Features:
* Bronze Impeller
* Ceramic Mechanical Seal Oil Bath
Applications:
* Water Supply, Pressurisation and Fire-Fighting Systems
* Cooling and Heating
* Irrigation, Industrial and Agricultrural Applications
Original: $1,143.26
-65%$1,143.26
$400.14
Description
Pentax CM Series - Irrigation and Washdown Pumps
The Pentax CM32 Monobloc horizontal centrifugal pumps, constructed to EN 733 standards; widely used in water supplies, pressurization and fire-fighting systems, cooling, heating, irrigation, industrial and agricultural applications; standard supply with counter-flange.
Specifications:
| Model | HP | kW | Flow Rate | Phase | Volts | Max Head | Inlet | Outlet |
| CM32-200C | 5.5 | 4.0 | 450LPM | Three | 400 | 40m | 50mm | 32mm |
| CM32-200A | 10 | 7.5 | 550LPM | Three | 400 | 58m | 50mm | 32mm |
* Inlet/Outlet Size: 50/32mm
* Liquid Temperature: -10 - +90 degrees
* Maximum Operating Pressure: 10Bar
* Enclosure Class: IP55
* Insulation Class: F
Features:
* Bronze Impeller
* Ceramic Mechanical Seal Oil Bath
Applications:
* Water Supply, Pressurisation and Fire-Fighting Systems
* Cooling and Heating
* Irrigation, Industrial and Agricultrural Applications
