TREVOLI - TDA150 - Spa Pool Pump - 1100w/1.5HP

The Trevoli TDA Series Spa Pool pump range are robust and powerful single speed centrifugal pumps with several motor sizes, designed to suit a large range of Spa pool sizes and applications. Robust, energy efficient and very quiet – the hallmarks of the Trevoli pool pump range.

Specifications:

*Motor 1100W (1.5hp)
*Max Flowrate 380 L/min (22,800 L/H)
*Max head 16M
*Inlet and Outlet diameter:40 mm.
*Weight 11.5 KG

Features:

*Corrosion protected shell to prevent water directly contacting with motor
*Pump body and impellor in highly reinforced engineering grade plastic, motor shaft stainless steel, aluminium motor housing.
*IPX5 protection.
*Insulation class F
*CE Authentication
*Mechanical seal is ceramic stealite/ metalized carbon.
*Rated for continuous use
*Very quiet operation

Applications:

*Spa Pool / Swimming Pool Pump suitable for 8 - 14 jets

Heater Option:

*Suits H30-R2

TWO YEAR WARRANTY

Trevoli Spa Pool Pump Data Sheet

Parts List
