DAVIES CRD SERIES STAINLESS STEEL SINGLE STAGE PUMPS

Please contact us regarding product as we don't always carry this item in stock

(Not all models are available, please enquire about availability)

220-CRD1-xxx

All Stainless steel wet end single impeller centrifugal pump for CIP (clean in place) applications, circulation and pressure boosting. High temperature rated with EPDM or Viton elastomers.

Specifications:

MODEL	HP	kW	PHASE	VOLTS
CRD1-030M	0.33	0.25	1	230
CRD1-050M	0.5	0.37	1	230
CRD1-050T	0.5	0.37	3	400
CRD1-100M	1.0	0.75	1	230
CRD1-100T	1.0	0.75	3	400
CRD1-120M	1.2	0.9	1	230
CRD1-120T	1.2	0.9	3	400
CRD1-150M	1.5	1.1	1	230
CRD1-150T	1.5	1.1	3	400
CRD2-100M	1.0	0.75	1	230
CRD2-100T	1.0	0.75	3	400
CRD2-150M	1.5	1.1	1	230
CRD2-150T	1.5	1.1	3	400
CRD2-200M	2.0	1.5	1	230
CRD2-200T	2.0	1.5	3	400
CRD2-250M	2.5	1.85	1	230
CRD2-250T	2.5	1.85	3	400
CRD3-100M	1.0	0.75	1	230
CRD3-100T	1.0	0.75	3	400
CRD3-150M	1.5	1.1	1	230
CRD3-150T	1.5	1.1	3	400
CRD3-200M	2.0	1.5	1	230
CRD3-200T	2.0	1.5	3	400
CRD3-250M	2.5	1.85	1	230
CRD3-250T	2.5	1.85	3	400



MODEL	HEAD	FLOW RATE	Outlet	Inlet
CRD1-030M	11m	80 LPM	25mm	32mm
CRD1-050M	16m	120 LPM	25mm	32mm
CRD1-050T	16m	120 LPM	25mm	32mm
CRD1-100M	26m	120 LPM	25mm	32mm
CRD1-100T	26m	120 LPM	25mm	32mm
CRD1-120M	31m	120 LPM	25mm	32mm
CRD1-120T	31m	120LPM	25mm	32mm
CRD1-150M	35m	120 LPM	25mm	32mm
CRD1-150T	35m	120 LPM	25mm	32mm
CRD2-100M	20m	180 LPM	25mm	32mm
CRD2-100T	20m	180 LPM	25mm	32mm
CRD2-150M	27m	180 LPM	25mm	32mm
CRD2-150T	27m	180 LPM	25mm	32mm
CRD2-200M	33m	180 LPM	25mm	32mm
CRD2-200T	33m	180 LPM	25mm	32mm
CRD2-250M	38m	180 LPM	25mm	32mm
CRD2-250T	38m	180 LPM	25mm	32mm
CRD3-100M	18m	260 LPM	25mm	40mm
CRD3-100T	18m	260 LPM	25mm	40mm
CRD3-150M	22m	260 LPM	25mm	40mm
CRD3-150T	22m	260 LPM	25mm	40mm
CRD3-200M	26m	260 LPM	25mm	40mm
CRD3-200T	26m	260 LPM	25mm	40mm
CRD3-250M	29m	260 LPM	25mm	40mm
CRD3-250T	29m	260 LPM	25mm	40mm



Technical Details:

*Maximum liquid temperature: +90°c
(Can run up to 110°c with a Viton Seal- please ask us about this if you need to reach this temperature)
*Minimum liquid temperature: -15°c
*Maximum casing pressure: 8Bar

Construction Materials:

*304 Stainless steel Pump body, seal plate, shaft & impeller
*Mechanical seal: Silicon carbide/Carbon/EPDM

Motor Features:

*Totally enclosed, fan cooled. Continuous rated
*2900 RPM, 50Hz 230V Single phase or 400Volts Three phase
*IP55 Protection
*Single phase version fitted with auto reset internal overload
*Three phase version requires user supplied overload

Applications:

*Dairy Vat wash
*Chilled water closed loop circulation
*Hot water washing and circulation
*Pressure boosting
*Filtration
*Wash-down

 Two Year Warranty
