Grundfos Sololift 2 Lifting Station

Please contact us regarding product as we don't always carry this item in stock

Grundfos SOLOLIFT2 is a unique range of compact lifting stations enabling a drain of any domestic sanitary appliance wherever needed, independent from the gravity drain system. The units collect and pump the wastewater through a thin pressure pipe (23mm) to the next down pipe – up to 6m high or 100m distance. Designed according to the needs of professionals – high reliability and easy, clean service in mind. They come ready to use with a plug and operate full automatic when water enters the tank.

Specifications:

Model	kW	Head (m)	Flow Rate lpm	Inlet	Discharge	Entry
SOLOLIFT2 C-3	0.62	8.8	204	100	22/25/28/32/36/40	Top- 32/36/40. Left & Right- 36/40/50
SOLOLIFT2 D-2	0.28	5.5	105	N/A	22/32	Left & Right-36/40/50 x2
SOLOLIFT2 WC-1	0.62	8.5	149	100	22/25/28/32/36/40	Inlet connection at top-32/36/40
SOLOLIFT2 WC-3	0.62	8.5	149L	100	22/25/28/32/36/40	Top- 32/36/40. Left & Right- 36/40/50
SOLOLIFT2 CWC-3	0.62	8.5	137	100	22/25/28/32/36/40	Top- 32/36/40. Left & Right- 36/40/50

(The numbers indicate how many additional inlet connections are possible)

Applications:

SOLOLIFT2- C-3- Suitable for pumping grey wastewater from a washing machine, dishwasher, bath tub, cabinet shower, washbasin or kitchen sink, or brine from water softeners.

SOLOLIFT2- D-2-Extremely compact variant for pumping grey wastewater from a washbasin, cabinet shower or bidet.

SOLOLIFT2- WC-1-Suitable for pumping wastewater from a toilet or washbasin.

SOLOLIFT2- WC-3-Suitable for pumping wastewater from a toilet, washbasin, cabinet shower and a bidet or urinal.

SOLOLIFT2- CWC-3-Suitable for pumping wastewater from a wall-hung toilet, washbasin, cabinet shower and a bidet or urinal.

Wherever the drain of a sanitary appliance is required but no gravity drain pipe is available or possible. The units with a WC connection are dedicated for installation in private homes only. Their compact measurement enables the integration in front-wall installation and floor units.

Features:

* Ready-to-install solution
* Highest reliability thanks to a high performance cutter and motor
* Handle accidently flushed female articles
* fast, easy and clean service – no need to remove the unit from installation
* All relevant service parts dry and clean accessible – not submerged in tank
* Easy access level switch units, single accessible for maintenance
* Pressure proof, welded tank system, leakage free in case of backwater
* Odour-free by venting valve with charcoal filter
* Maintenance free tank design reducing clogging risk
* Hot water resistant up to 90°C for 30 min.
* Very compact design
* Low start levels enable modern, flat shower trays
* Selectable outlet direction (top and side)
* Height adjustable inlet connectors ease installation and replacement
* Up to 4 inlet pipe and 6 pressure pipe connection selectable
* All units LGA-, VDE-, EMC- and GOST- approved

Sololift Brochure

Sololift Technical Brochure

2 Year Back to Base Warranty
